Kawasaki KX 450 F (KX 450 H) [2016-2018] - WÖSSNER forged pistons

WÖSSNER forged pistons for Kawasaki KX 450 F

The WOSSNER forged piston is designed for the Kawasaki KX 450 F (KX 450 H) in the entire 2016-2018 model year range. The version with standard piston compression is suitable as a precisely defined replacement component for the engine of this vehicle classification.

Design and technical features

• Piston type: forged
• Material: aluminum
• Piston skirt with anti-friction coating
• Piston compression: standard
• Diameter Ø: 95.96 mm
• Letter oversize: B
• Oversize: +0.01

The forged construction and the aluminum piston are tailored to the specified dimensions of this version. The anti-friction coating on the piston skirt is a specific feature of the component and supports the functional design of the piston in the engine.

Scope of delivery

• WOSSNER forged pistons
• Piston rings
• Required segments
• circlips
• screws

Vehicle assignment

The forged piston fits the Kawasaki KX 450 F (KX 450 H), built between 2016 and 2018. The specified diameter of 95.96 mm, the letter B and the oversize +0.01 are particularly important for the selection.

WOSSNER forged pistons are manufactured in Germany by specialists in 2- and 4-stroke engine parts. The specific design combines the specified standard piston compression with the dimensions and delivery features mentioned.
