Kawasaki KX 250 F (KX 250 T) [2006-2008] - forged pistons

VERTEX forged pistons for Kawasaki KX 250 F (KX 250 T)

The VERTEX forged piston is assigned to the Kawasaki KX 250 F (KX 250 T) in the full year range from 2006 to 2008. The design is suitable as a precise choice for the engine design if the specified piston and bore dimensions match the existing cylinder.

Pistons with defined dimensions

The piston is made of aluminum and is forged. The high compression is identified as a technical feature. The diameter of 76.96 mm, the bore diameter of 77.00 mm, the letter of the oversize B and the oversize specification +0.01 are relevant for the selection of dimensions.

Technical data

• Brand: VERTEX
• Component: forged piston
• Material: aluminum
• Piston Type: Forged
• Piston compression: high compression
• Diameter Ø: 76.96 mm
• Letter oversize: B
• Oversize: +0.01
• Bore diameter: 77.00 mm
• Rings Quantity: Set
• Stroke: 4T

Vehicle assignment

Suitable for Kawasaki KX 250 F (KX 250 T), built between 2006 and 2008. Before making a selection, the listed dimensions, the oversize B and the +0.01 specification should be compared with the intended cylinder and the desired engine structure.
